Plus 5 PL 8549

Plus5 PL 8549 is a nucleated, antistatic formulated, high fluidity heterophasic copolymer used for thin walled injection molding.



Plus5 PL 8549  Description

Plus5 PL 8549 is a nucleated, antistatic formulated, high fluidity heterophasic copolymer used for thin walled injection molding. Items made with " Plus5 PL 8549 "exhibit high stiffness, relatively good impact resistance and excellent antistatic properties. The finished items show good mechanical properties, and high dimensional stability. " Plus5 PL 8549 "is very well suited for the production of thin-walled articles or articles with long flow paths such as flower pots, containers, housewares, filters, filters housings and appliance is suitable for food contact.

Heterophasic poly(propylene) copolymers obtained by sequential polymerization are multi-component products formed by a crystalline matrix of poly(propylene) and an ethylene-propylene rubber phase. Some crystalline polyethylene and poly(ethylene-co-propylene) are formed in the rubber synthesis step by copolymerization of ethylene and propylene. These multi-component systems present a complicated microstructure and heterophasic morphology.


Typical Applications Plus5 PL 8549
  • Thin-walled articles,
  • Thin-walled articles,
  • Articles with long flow paths such as flower pots,
  • containers,
  • housewares,
  • filters,
  • filters housings and appliance,
  • components,
  •  Sports,
  • Leisure and toys.

Approval
  Food (FDA compliant)



 Technical properties
METHOD  UNIT  VALUE  TYPICAL PROPERTIES



ASTM D1238

ASTM D1505



g/10 min

g/cc



21

0.9

Physical

Melt flow rate (230 ֯ c, 2.16 kg)

Density



ASTM D790

ASTM D638

ASTM D638

ASTM D256

ASTM D256



MPA

MPA

%

J/m

J/m



1500

26

6

90

40

Mechanical

Flexural modulus

Tensile Strength at Yield

Tensile Elongation at Yield

Izod impact strength (notched) at 23 ֯ c

Izod impact strength (notched) at -20 ֯ c



ASTM D1525

ASTM D648

ASTM D3012



֯ c

֯ c

hours



150

110

360




Thermal

Vicat softening point (9.8 N)

H.D.T (0.46 mpa)

Accelerated oven ageing in air at 150 ֯ c
